24V DC 0.75kW 750W 1HP 1700rpm Type 50 Motor & Worm Gearbox Drive i20
24V DC 0.75kW 750W 1HP 1700rpm Type 50 Motor & Worm Gearbox Drive i20
Specifications:
- Power: 0.75Kw (1HP)
- Voltage: 24V DC
- Amperage/Current: Approx. 42A
- Speed: 1700rpm
- Duty: Continuous
- Power: 750 Watt
- Enclosure: TENV
- Frame: 80B14
- Max Temperature: 40°C
- Output Speed: 85 rpm
- Max. output torque: 67 Nm
- Output Shaft Size: 25mm (Hollow Output Shaft)
- Gearbox Size: Type 50
- Reduction: 20:1
- Service Factor: 1.0
- Duty: S1
Features:
- Epoxy Painted – Black Colour
- Rolled steel construction
- Totally Enclosed Non Ventilated
- Low noise and vibration
Dimensional Drawing:
Suitable Applications:
- Hoists / Winches
- Compressors
- Conveyor Drives
- Pump Drives
- Automation Devices
- Food / Pharmacy Packaging
- Pulley drives
- Fans
- Food Processing
Optional Accessories (Available on request):
- IEC Flange/Foot Mounting
- Slide Rails
- Industrial Gearboxes
- Couplings
- Pulleys
- Chain Drives
Dimensions:
We also have both Single and Three Phase electric motors between 0.18Kw to 315Kw in 2, 4, 6 and 8 pole.
