$903.50
12V DC 0.37kW 370W 0.5HP 1700rpm Type 63 Motor & Worm Gearbox Drive i60
12V DC 0.37kW 370W 0.5HP 1700rpm Type 63 Motor & Worm Gearbox Drive i60
Specifications:
- Power: 0.37Kw (0.5HP)
- Voltage: 12V DC
- Amperage/Current: Approx. 42A
- Speed: 1700rpm
- Duty: Continuous
- Power: 370 Watt
- Enclosure: TENV
- Frame: 71B14
- Max Temperature: 40°C
- Output Speed: 28.3rpm
- Max. output torque: 78Nm
- Output Shaft Size: 25mm (Hollow Output Shaft)
- Gearbox Size: Type 63
- Reduction: 60:1
- Service Factor: 1.4
- Duty: S1
Features:
- Epoxy Painted – Black Colour
- Rolled steel construction
- Totally Enclosed Non Ventilated
- Low noise and vibration
Dimensional Drawing:
Suitable Applications:
- Hoists / Winches
- Compressors
- Conveyor Drives
- Pump Drives
- Automation Devices
- Food / Pharmacy Packaging
- Pulley drives
- Fans
- Food Processing
Optional Accessories (Available on request):
- IEC Flange/Foot Mounting
- Slide Rails
- Industrial Gearboxes
- Couplings
- Pulleys
- Chain Drives
We also have both Single
